Up to 1000 mA, Universal Laser Diode Controller

$1,570.00

PART NUMBER : ULDC-1000-MC

The Optilab ULDC-1000-MC is a fully integrated universal laser diode controller designed for butterfly laser diode. This compact, easy to use laser diode driver module operates under a single + 12 V DC power supply. ULDC-1000-MC offers LD current and temperature control that comes with a built in OLED display and a USB port for external PC control. The module is equipped with an adapter board, thus making it compatible with butterfly LD module for any laser manufacturers by switching the daughter boards provided in the package. It features LD current range of 0 to 1000mA with a setting resolution of 1 mA and temperature range of 10 ℃ to 40 ℃ with a setting resolution of 0.1 ℃.

FEATURES
Up to 1000 mA LD Current
2.3 A TEC Current
ZIF Socket
On Board OLED Display
USB Port for External PC Control
Compatible with Arbitrary Pinout

USE IN
Laser Diode Characterization
Research and Development
Laboratory Use
Failure Analysis

Lead Time: Please contact sales
